The River Station tag defines where the bridge will be located within the specified reach. The reach label defines which reach the bridge will be located in. The River and Reach boxes allow the user to select a river and reach from the available reaches that are defined in the schematic diagram. A description of this information follows:

The required information for a bridge consists of: the river, reach, and river station identifiers a short description of the bridge the bridge deck bridge abutments (if they exist) bridge piers (if the bridge has piers) and specifying the bridge modeling approach. Press the Apply Data button for the interface to accept the data.

Optional bridge information is found under the Options menu at the top of the window.

Enter any desired optional information.

Enter all of the required data for the new bridge.

An input box will appear prompting you to enter a river station identifier for the new bridge.

Go to the Options menu and select Add a Bridge and/or Culvert from the list.

Selecting a reach is accomplished by pressing the down arrow on the river and reach box, then selecting the river and reach of choice.

Select the river and reach that you would like to place the bridge in.

To add a bridge to the model, do the following: Once the bridge/culvert button is pressed, the Bridge/Culvert Data Editor will appear as shown in Figure 5-12 (your bridge/culvert editor will come up with a blank window until you have entered the bridge data). To enter bridge data the user presses the Bridge/Culvert button on the geometric data window (Figure 5-1).
